XK-GS310 portablecamera control station , the appearance of the suitcase design, easy to carry, using a bright screen, visible in the sun, configured with the mainstream WINDOWS operating system, can be pre-installed with a variety of software. Built-in lithium battery pack, can be continuously powered to maintain equipment work for 3 hours, suitable for long time field mission.

Technical Parameter
Box Type	Military three-proof safety box
Overall Dimensions	556MM(L)*358MM(W)*230MM(H)
Weight	15KG
Shell material	PVC
IP rating	IP67
Working Temperature	-20°C~ 60°C
Colour	Matte black
Portable Features	Built in pull rod, external lifting cover
Battery and endurance	4 hours
Operation Panel
Panel material	3K Carbon fiber plate
Interface support	USB*2,DC IN,HDMI,RJ45
Feeder and interface	N,SMA
Human-computer interactin	Industrial mouse button suit
Switch parameters	Main power supply, power on key, link power supply
Others	Industrial cooling fan
Industrial Control Host
Processor	I5 6500T
Operating system	Windows 10
Memory	8G
Hard disk	256G
I/O Interface	USB,Network port,Serial port,HDMI
Left and right dual display
Dimensions	20 inches
Resolution ratio	1920*1080
Screen scale	16:9
Backlight type	LED
Maximum brightness	1000nit(Automatic induction regulation)
Input interface	HDMI
Remote lever and button functions
Joysticks	*2 Industrial joysticks with Hall's sensors
Paddle	*4
Knob	*2
Push-button	*4
Communication protocol	SUBS,USB HDI
Battery & Power
Display contents	Current voltage, current,current residual capacity, power, etc
Management system protection	Overcurrent protection,overvoltage protection, lowvoltage protection, overcapacity protection
Battery protection	Overcurrent protection, overtemperature protection, overvoltage protection and low voltage protection
Endurance	4 hours
