Bamboo lab A1 AMS Lite Mini Combo

Mini body maximum efficiency

The compact size of only 25x25 cm makes it suitable for installation in any environment. In addition, it is equipped with the AMS Lite multi-color automatic feeding system, which adapts perfectly to the desktop and allows printing 4 colors simultaneously.

Automatic monitoring and adjustment of the belt

A loose strap can lead to a reduction in the print quality. The A1 mini automatically checks the tension of the belt by calibrating the vibration frequency. If the belt tension is outside the range calibrated by the algorithm, the HMS health management system notifies you and automatically adjusts the belt tension.

Quiet and moisture-proof design

Enhanced sealing dry box, the shelf life of consumables is extended to 6 months after opening. Equipped with night mode: APP setting 22:00-6:00 automatically reduces the speed to 35dB below the sound of the air conditioner operation

Plug and play, essential for beginners

The A1 mini comes pre-assembled, precisely pre-calibrated and pre-leveled. It's ready for your first impression in just 20 minutes, with no need for manual adjustments.

Automatic adjustment of X and Y resonance prior to each print

A1 Mini has sensors on the tool head and the thermal base. One of the first flatbed printers to perform automatic resonance calibration on the X and Y axes

Volume of construction: 180x180x180mm & sup3;
Chassis: Steel + extruded aluminum

Head of tool

Hot End: all metal
Extrusion gears: steel-reinforced
Nozzle: Stainless steel
Maximum temperature of hot end: 300
Nozzle diameter (included): 0.4mm
Nozzle diameter (optional): 0.2mm, 0.6mm, 0.8mm
Cutter of filament: Yes
Filament Diameter: 1.75mm

Thermal Bed

-Compatible construction board: Textured PEI bamboo board
PEI-flat bamboo board
Maximum temperature of the building plate: 80

Speed

Max speed of tool: 500 mm/s
Maximum acceleration of tool head: 10000mm/s²
Max flow of hot end: 28mm & sup3;/s @ ABS

Cooling

Partial-cooling fan: Closed-loop control
Hot-end fan: Closed-loop control
Cooling fan of the MC board: Closed-loop control

Filament supported

PLA, PETG, TPU, PVA: Ideal
ABS, ASA, PC, PA, PET, carbon fiber/glass-reinforced polymer: not recommended

Sensors

Monitoring camera: Low speed camera (up to 1080P) compatible with Timelapse
Filament-Exhaust Sensor: Yes
Odometry of filament: Yes
Recovery from loss of energy: Yes
Sensor of entanglement of filaments: Yes

Physical dimensions

Dimensions: 347x315x365mm & sup3;
Net weight: 5.5 kilos

Electrical requirements

Input Voltage: 100-240 VAC, 50/60Hz
Maximum power: 150 W

Electronics

Display: 2.4-inch IPS touch screen 320*240
Connectivity: Wi-Fi, Bamboo-Bus
Storage: Micro SD card
Interface of control: touch screen, application, application for PC
Motion Controller: Cortex M4 Dual-Core

Software

Cutter: Bamboo Studio supports third party cutters that export the Gcode standard, such as SuperSlicer, PrusaSlicer, and Cura, but
Certain advanced features may not be compatible.
Operating system compatible with the cutter: Mac OS, Windows

Wifi

Frequency range: 2412 MHz - 2472 MHz (CE)
2412 MHz - 2462 MHz (FCC)
2400 MHz-2483.5 MHz (SRRC)
Transmitter Power (PIRE): 21.5 dBm (FCC)
20 dBm (CE/SRRC) Protocol
: IEEE 802.11 b/g/n

SPECIFICATIONS OF PRODUCT
• Type of 3D printer: Filament
• Brand: Bamboo Lab
• Model: A1 mini AMS Lite Combo
