- Origin: Mainland China
- spindle taper: BT40
- no. of spindles: 3
- type: VERTICAL
- dimension(l*w*h): 4300*2300*2550mm
- weight (t): 6.2
- table size (mm): 850x650
- cnc control system: GSK
- table travel (x) (mm): 1100
- table travel (y) (mm): 600
- table travel (z) (mm): 600
- positioning accuracy (mm): 0.01
- repeatability (x/y/z) (mm): 0.003
- range of spindle speed(r.p.m): 100 - 8000 r.p.m
- max. table load(kg): 800
- min. time of tool change(s): 1
- tool magazine capacity: 24
- key selling points: Competitive Price
- warranty: 1 Year
- place of origin: China
- brand name: RICHON
- voltage: as per customer's request
- machinery test report: Provided
- video outgoing-inspection: Provided
- machining capacity: Medium Duty
- rapid feed speed(mm/min): 0 - 32000 mm/min
- Machine Type: CNC Vertical machining center
- CNC controller: GSK FANUC SIEMENS
- Function: metal processing
- Model: VMC1160
- Main Motor Power: 11kw
- Spindle Max. Rotating Speed: Servo Spindle 8000rpm
- Worktable Size: 1100x600mm
- Distance of Spindle to Guideway Plane: 650mm
Friends, welcome to our store! If you need other models of this product, customized products or inquire about shipping costs, please contact me and I will send you the product link to purchase!
Please contact me for more details and discounts:
Sales Director: luna；
Whatsapp: +86 13677461310；
Email: 615749913@qq.com；
Please read the following carefully:
Shipping: Due to the large size and weight of this product, sea freight is recommended.
For specific delivery times and shipping discounts, please contact the Sales Director before payment.
If you have any questions, please feel free to contact us!
Products Description
CNC Vertical Machining Center VMC1160 series
|
Model
|
VMC1160
|
|
Main Motor Power KW
|
11KW
|
|
Spindle Max. Rotating Speed
|
Servo Spindle 8000rpm
|
|
Spindle Taper
|
BT40
|
|
Worktable Size
|
1200*600mm
|
|
Travel(Longitudinal X/Horizontal Y/Vertical Z)
|
1100/600/600mm
|
|
Positioning Accuracy
|
±0.01mm
|
|
Repeated Positioning Accuracy
|
±0.003/300mm
|
|
Magazine Capacity
|
24
|
|
System Configuration
|
GSK, FANUC, SIEMENS
|
|
External Protection Level
|
Full Closed
|
|
Max. weight load
|
800kg
|
