- Hign-concerned Chemical: None
- Certification: ce
- Origin: Mainland China
- Brand Name: ACCTEK
- Model Number: AKJ1530FBCR/AKJ2560FBCR
- Certification: CE
- Machine name: Enclosed laser cutting machine
- Working size: 1500*3000mm/2500*6000mm
- Tube length: 6m/3m
- Servo motor: Japan Yaskawa servo
- Guide rail: Taiwan Hiwin square guide rails
- Control system: Cypcut
- Laser head: Raytools/Boci
- Cooling way: Water chiller
- Reducer: French Motoreducer
- Working voltage: 3 Phase, 380V, 50/60 HZ
- key words: 6kw Cnc Enclosed Laser Cutter
Ultra Power 12kw 6kw Cnc Enclosed Laser Cutting Cutter Machine With Double Work Tables
Feathers of 6kw Cnc Enclosed Laser Cutter
◆ Industrial welded frame and high-temperature stress relieving treatment ensure long-term use of no deformation.
◆ Adopt Japan THK linear rail, wear-resistant, dust-proof and smooth.
◆ Adopt Japan SHimpo reducer, capable for high speed and high accuracy metal processing.
◆ Adopt France Schneider AC servo system ensure high power and torque force.
◆ Auto restart after power blackout and continue previous process.
◆ High accuracy industrial camera provides high positioning precision.
◆ Independent control cabinet, seperated strong power and weak power design, easy to maintain.
◆ Compatible with mainstream CAD/CAM software like Type3/Artcam/Castmate/Probe/UG/Artgrave etc.
◆ Industrial matrix vacuum system as standard configuration.
◆ Industrial chiller with double temperature control module ensures high cooling efficiency for laser equipment.
◆ Manual lubrication system makes maintenance easier & low-cost.
Parameters of 6kw Cnc Enclosed Laser Cutter
Technical Parameter | AKJ1530FBCR/AKJ2560FBCR |
Power | 1000-20000W |
Processing Format (L*W) | 3000*1500mm/2500*6000mm |
X/Y-axis Positioning Accuracy | ±0.03mm/m |
X/Y-axis Repositioning Accuracy | ±0.03mm |
Acceleration | 2.0G |
No-load Speed | 180m/min |
Overall Dimensions (L*W*H) | for 1530: 8900*2260*2200mm |
cutting speed | 140m/min |
Acceleration speed | 1.5G |
