R$ 401.674,49
Credit subject to approval.
Any Questions? Check our Help.
Descrição
- Type: Other
- Origin: Mainland China
- Condition: New
- Type: Horizontal
- Max. Length of Workpiece (mm): 450
- Structure: Slant Bed Lathe
- Max. Spindle Speed (r.p.m): 3500 r.p.m
- Machining Capacity: Heavy Duty
- Spindle Bore(mm): 75
- Width of bed (mm): 30 mm
- Spindle Motor Power(kW): 11/15
- No. of Spindles: Single
- Number of Axes: 2
- Travel (X Axis)(mm): 170 mm
- Travel (Z Axis)(mm): 450 mm
- Positioning Accuracy (mm): 0.016
- Repeatability (X/Y/Z) (mm): 0.008
- Place of Origin: Zhejiang, China
- Dimension(L*W*H): 2800x1720x1775mm
- Brand Name: Z-MaT
- Model Number: STL8 Plus
- Voltage: Adjustable
- Tool Post Stations: 12, 8, 10
- Weight (KG): 3700
- Warranty: 2 years
- Applicable Industries: Machinery Repair Shops, Manufacturing Plant, Autopart making
- Key Selling Points: High Rigidity, High cost-performance
- Marketing Type: Hot Product 2019
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Warranty of core components: 2 years
- Core Components: Bearing, Gear, PLC
- CNC or Not: CNC
- Chuck size: 8", *10"
- Max. turning length: 400mm
- Max. swing diameter over slide: 280mm
- Spindle bore: 62mm
- Center height: 100mm
- Machine Type: Horizontal CNC Lathe
- Function: End-facing/ cylinrical turning/grooving
- Power(W): 7.5kW main motor
- After-sales Service Provided: Online support
The machine price various according to different configurations, contact us for more details. Direct sale factory of Zmat:cnc milling machine/CNC lathe machine/CNC turning machine...
