STL8 Plus Heavy Cut Slant Bed 8-Station Turret turning center cnc lathe machine/CNC milling/CNC turning

, Author

R$ 401.674,49

Up to 12 installments without cards through Mercado Pago. Learn more
Buy through Mercado Pago without cards and pay month by month
1
Add your product to the cart and, for the payment, select “Meses sin Tarjeta” or “Cuotas sin Tarjeta”.
2
Log in to Mercado Pago.
3
Choose the amount of installments that best suit you and you’re all set!

Credit subject to approval.

Any Questions? Check our Help.

REF: 1005005948328351

Descrição

  • Type: Other
  • Origin: Mainland China
  • Condition: New
  • Type: Horizontal
  • Max. Length of Workpiece (mm): 450
  • Structure: Slant Bed Lathe
  • Max. Spindle Speed (r.p.m): 3500 r.p.m
  • Machining Capacity: Heavy Duty
  • Spindle Bore(mm): 75
  • Width of bed (mm): 30 mm
  • Spindle Motor Power(kW): 11/15
  • No. of Spindles: Single
  • Number of Axes: 2
  • Travel (X Axis)(mm): 170 mm
  • Travel (Z Axis)(mm): 450 mm
  • Positioning Accuracy (mm): 0.016
  • Repeatability (X/Y/Z) (mm): 0.008
  • Place of Origin: Zhejiang, China
  • Dimension(L*W*H): 2800x1720x1775mm
  • Brand Name: Z-MaT
  • Model Number: STL8 Plus
  • Voltage: Adjustable
  • Tool Post Stations: 12, 8, 10
  • Weight (KG): 3700
  • Warranty: 2 years
  • Applicable Industries: Machinery Repair Shops, Manufacturing Plant, Autopart making
  • Key Selling Points: High Rigidity, High cost-performance
  • Marketing Type: Hot Product 2019
  • Machinery Test Report: Provided
  • Video outgoing-inspection: Provided
  • Warranty of core components: 2 years
  • Core Components: Bearing, Gear, PLC
  • CNC or Not: CNC
  • Chuck size: 8", *10"
  • Max. turning length: 400mm
  • Max. swing diameter over slide: 280mm
  • Spindle bore: 62mm
  • Center height: 100mm
  • Machine Type: Horizontal CNC Lathe
  • Function: End-facing/ cylinrical turning/grooving
  • Power(W): 7.5kW main motor
  • After-sales Service Provided: Online support

The machine price various according to different configurations, contact us for more details. Direct sale factory of Zmat:cnc milling machine/CNC lathe machine/CNC turning machine...
