Scanner Intraoral 3D Digital Portátil Runyes 3.0 Pro – Sistema de Imagem Odontológica de Alta Precisão
Specification:
Handpiece Dimension (L × W × H): 240mm×49.5mm×30.5mm
Weight: 210g
Standard tip size: 79mm×19.7mm×15.8mm
Mini tip size: 80mm×16mm×11mm
Scan area (Standard): 15mm×15mm
Scan area (Mini): 12mm×12mm
Depth of field: 15mm
Autoclavable: Up to 100 times Autoclavable 121℃ 16 mins Autoclavable 134℃ 4 mins
Accuracy:
Crown < 10μm
Full arch < 20μm
Scan Speed:
Single arch: 30 s
Full arch with occlusion: 90 s
Output: STL, OBJ, PLY
Connectivity: USB 3.0
Support Languages: Chinese，English, French, Spanish, Russian, Portuguese, Italian, Greek, Polish, Romanian, Japanese and Korean.
Packing:
Scanner handpiece (with protective tip and cable) x1
Type C to USB Converter x1
Base x1
Scanner tip (standard t =2, Mini tip = 1)
U disk with software x1
Characteristics
1.Superior image quality based on advanced CMOS technology.
2.More portable 3D acquisition process.
3.Smaller and more comfortable, durable scanning head.
3DS Scanner Main Features:
Data openness Can choose any repair design software, EXOCAD, 3Shape. Optional output axis for better interface with design software
◆Supportable languages
English,Spanish,Russian,Portuguese,Italian,Greek,Polish,Romanian,Japanese and Korean.
◆Intended use
Using optical scanning method to collect the 3D geometric data of the tooth in the patient's mouth and provide the 3D digital model for CAD/CAM denture design and processing.
◆High quality
The excellent image quality is based on advanced CMOS technology. The more convenient three-country collection process is more compact and comfortable, durable scanning tip easy to use USB 2.0 interface.
◆Ergonomic Scanner Tip Design
The new scanner tip with internal heating system keeps the temperature inside the patient's mouth constant. The mirror angle of the scanner tip is close to 45 degrees and can scan the mesial and distal areas in line.
◆Screw Type Cable Connection
The new screw cable connection provides a more secure connection between the cable and the handpiece.
◆Aesthetic and Lightweight Handpiece Design
The ergonomic design and light weight (210g) of the handpiece make it more comfortable and easy to use.
◆New Al Scanning Function
The Intraoral Scanner's new Al function scans soft tissues more smoothly and ensures cleaner results. Suitable for edentulous jaw optimization, caries detection and automatic labeling.
◆3D True Color
The surface texture and contrast of scanned elements are stronger. This helps dentists and technicians perform more precise procedures.
