- Químico Hign-em causa: Nenhum
- Origem: CN (Origem)
The price not included shipping,please contactLiz Lee before order
.We will quote you best shipping cost.We will offer you gifts and coupon.
Whatsapp+86 18202744148 Email: liz@raylinenc.com
Parameter
|
Laser Type
|
Fiber laser
|
|
Laser Power
|
20W 30W 50W 60W
|
|
Model
|
CN-20W/30W/50W/60W
|
|
Laser Wavelength
|
1064nm
|
|
Marking Area
|
75*75mm 110*110mm 150mm*150mm 175mm*175mm 200*200mm 300*300mm
|
|
Marking Depth
|
≤1.2mm
|
|
Marking Speed
|
10000mm/s
|
|
Minimum Line Width
|
0.012mm
|
|
Minimum Character
|
0.15mm
|
|
Repeated Precision
|
±0.003mm
|
|
Life-span of Fiber Laser Module
|
100 000hours
|
|
Beam Quality
|
M2 <1.5
|
|
Focus Spot Diameter
|
<0.01mm
|
|
Output Power of Laser
|
10%~100% continuously to be adjusted
|
|
System Operation Environment
|
Windows XP /7/8/10 32/64bits
|
|
Temperature of Operation Environment
|
15℃~35℃
|
|
Power Input
|
220/110v single phase
|
|
Power Requirement
|
<400W
|
|
Communication Interface
|
USB
|
|
Machine Dimension/after package
|
760*680*770mm
|
|
Optional
|
Rotary Device, Moving Table, other customized Automation
|
