- High-concerned chemical: None
- Engraving Area: Other
- Laser Power: Other
- Certification: CE
- Is Smart Device: Yes
- Origin: Mainland China
- Certification: ce
- Brand Name: ACCTEK
- Model Number: AKJ1350F
- Power: 1.5-40kw
- Power requirements: 220V, 50/60Hz,1phase
- Cutting head: Au3tech
- Controller: Au3tech SC2000
- Generator: Max/Reci
- Transmission: Gear and pinion transmission
- Gear and rack: Taiwan YYC gear and rack
- Motor: Delta servo motor XY axis 750w Z axis 400w
- Drive: Delta ( Y axis dual-drive)
- Reducer: French MOTOREDUCER
- Guide rails: Taiwan HIWIN 25mm square guide rails
- Water chiller: S&A water chiller
Contact us before you pay,as different price based on different configuration:
Eva Huang
whatsapp/wechat:+86 13245315929
Email:export19@acctekgroup.com
JINAN ACCTEK MACHINERY CO.,LTD
Brief introduction
ACCTEK fiber laser cutting machine adopts Max/RAYCUS/Reci/JPT/IPG laser source which has international advanced laser technology.
Equipped with an efficient transmission system by Taiwan high-precision gear rack after grinding process and high-precision linear guide.
Advanced Au3thch control system, group into high precision CNC fiber laser cutting machine.
Main Features of Fiber Laser Cutting Machine
1. Application of gantry structure and integrated cast cross-girder to achieve higher rigidity, stability, shock resistance.
2. High-performance laser source and stable operating Au3tech system which makes the best cutting effect.
3. The machine owns a perfect cooling system, lubrication system, and dust removal system, to ensure that it can operate stably, efficiently, and durably.
4. The machine is capable of automatic height adjustment to maintain constant focal length and stable cutting quality.
5. The specialized CAD / CAM automatic programming software and automatic nesting software aim to maximally save raw materials.
Parameter for Fiber Laser Cutting Machine
Working area | 1500*3000mm |
Control System | Au3tech controller with auto follow system |
Laser head | Au3tech brand laser cutting head |
Guide rail | Taiwan HIWIN linear guide rail 25mm |
Transmission | Rack and pinion |
Electronic Components | French Schneider |
Motor | Taiwan Delta 750w servo motor |
Max Cutting Speed | 40m/min |
X axis max speed | 65m/min |
Y axis max speed | 70m/min |
Z axis max speed | 30m/min |
X axis max acceleration | 1G |
Y axis max acceleration | 1G |
Cooling Way | Water Cooling |
Minimum line width | 0.1mm |
Power Requirements | 220V, 50/60Hz, 1phase |
Continuous Working Time | 24Hours |
Machine Details
Cutting head:Au3tech Laser Cutting Head, Optimized optical configuration and smooth and efficient airflow design.
Multiple language are available
Fiber Laser Generator:
Raycus/JPT/Reci/Max/IPG fiber laser generator
High beam quality and stable performance.
Water chiller
S&A water chiller（the best water chiller brand in China）
Specially developed for fiber laser equipment, excellent cooling effect.
Stable and reliable performance, low failure rate, energy saving and high efficiency.
Other Accessories
Customer Feedback
After receiving the package
1.Unpack and check if the machine is safety.
We give sea shipping insurance in CIF, if it's broken, call the insurance company please.
2. Check all the parts are included.
If any part is missing, contact our sales please, we'll send you.
3. Check the operation video and manuals.
Follow the vidoe or manuals to start the machine.
4. If need help, contact service team.
Our sales service team can answer your questions online, help you start the machine.
