Attention: 365mm Z height version includes 3mm aluminum composite side panels, there are no side panels for 465mm and 665mm Z height version.This price does not contain prints

9*  2040 aluminum extrusion 496mm (Wide Beams) ( 1 piece more, if you choose 465mm or 665mm Z height version)

3*  2020 aluminum extrusion 576mm (Aux wide Beams)

1*  2020 aluminum extrusion 460mm (X axis)

4*  2040 aluminum extrusion 560mm (4 corners height beams)  (660mm or 860mm,if you choose 465mm or 665mm Z       height version)

2*  2040 aluminum extrusion 442mm (Z axis)( 542mm or 742mm)

2*  2020 aluminum extrusion 405mm (bed frame)

2*  2020 aluminum extrusion size: for CR-10 bed: 173mm

2* T Shape Bracket 60x60

14*  Corner 90 degrees Angle Bracket for 2020/2040

100*  aluminum 2020 Brackets 20x20 20x17(104pcs aluminum 2020 Brackets,if you choose 465mm or                                 665mm version)

5*  Hiwin Mgn12H Carriage + Hiwin 400mm Rails( 2pcs of 500mm or 700mm Z rails, if you choose 465mm or 665mm          version)

2*  GT2 Pulley 16 Teeth 5mm bore (mounted on X/Y steppers)

24*  F623 ZZ Flange Ball Bearings

2*  635ZZ bearings

1*  4m Gates 6mm GT2 Fiber Glass Reinforced Belt

2*  Lead Screw Diameter 8mm Lead8mm 400mm( 2pcs of 500mm or 700mm,  if you choose 465mm or 665mm                   version)

2*  Aluminum Coupler 8x5x25mm

1*  Motors kit(17HM19-2004S Nema17 0.9deg 46Ncm 2A,17HS19- 2004S1 59Ncm 1.8deg 2A,17HS16-2004S1 Nema17         45Ncm 1.8deg 2A)

1*  DUET 2 WIFI mainboard

1*  4.3" inches LCD

1*  Logic Level Shifter

1*  LM2596 board

1*  Node Mcu Lua WIFI V3 Board

1*  V6 clone hotend (1.75 24V)

1*  Mini differential IR height sensor with cable

1*  Meanwell 24V, 18.8A PSU

1*  Power cable Cord(EU/AU/US/UK)

1*  Socket kit(including wires)

2*  Omron endstop switch

3*  NeoPixel Ring 16 leds WS2812 Module

1*  wires kit

6*  Wago 3pins Connector

1*  Wago CompactWiring 4 pins Connector

1*  16mm Momentary switch with led 110V/220V

2*  16mm Momentary switch with led 24V blank icon

1*  Magnets 310*310*3mm heated bed

1*  PEI sheet

3* 4010 fans 24V

1*  5015 Blower fan 24V ball bearings 24V

1*  121225 fan

1*  BMG dual extruder

1*  Black Wrap Braided Cable Sleeve 12mm OD, 1M

1*  Black Wrap Braided Cable Sleeve 5cm OD, 1M

1*  5M LED strip 5050 60 leds

1*  activated carbon filter

3*  Hepa Filter for ilife vacuum robots

1*  2x4 PTFE tube 1 meter

1*  3mm aluminum coposite panels kit

Screws kit

M2.5*12mm Flat Head Machine Screws

M3*14mm Phillips round head

M3*18mm Phillips round head

M3*22mm Phillips round head

M3*25mm Phillips round head

M4*40mm flat screws

M4*30mm Hexagon head

M5*10mm screws

M5*16mm screws

M5*35mm screws

M3*8mm Socket Head Cap Screw

M3*10mm Socket Head Cap Screw

M3*12mm Socket Head Cap Screw

M3*16mm Socket Head Cap Screw

M3*18mm Socket Head Cap Screw

M3*22mm Socket Head Cap Screw

M3*25mm Socket Head Cap Screw

M3*30mm Socket Head Cap Screw

M3*35mm Socket Head Cap Screw

M3*40mm Socket Head Cap Screw

M3*50mm Socket Head Cap Screw

M3 0.5mm Washer

M5 washers

M3 nuts

M3 Nyloc nuts

M4 Nut

M4 T-nut

M5 T-nut

M3*8mm screws and M3 T-nuts(60PCS)

M4 adjusting nuts

Heated bed adjusting wheels

tension springs
