Descrição
- DIY Supplies: ELECTRICAL
- Origin: Mainland China
- Certification: CE
- Application: LASER CUTTING
- Applicable Material: Glass, Metal,Metal, Silver, Crytal
- Condition: New
- Laser Type: Fiber Laser
- Cutting Area: 600mm*600mm, can be customized
- Cutting Speed: 80m/min
- Graphic Format Supported: AI, PLT, DXF, BMP, Dst, Dwg, LAS, DXP
- Cutting Thickness: 1-8mm, 0-8MM
- CNC or Not: Yes
- Cooling Mode: WATER COOLING, water cooling
- Control Software: cypcut
- Place of Origin: guangdong
- Brand Name: OPTIC
- Laser Source Brand: RAYCUS
- Laser Head Brand: Raytools
- Servo Motor Brand: Huazhong
- Guiderail Brand: HanJiang
- Control System Brand: Cypcut
- Weight (KG): 800 KG
- Key Selling Points: High Productivity
- Warranty: 2 years
- Applicable Industries: Building Material Shops, Manufacturing Plant, Machinery Repair Shops,
- Machinery Test Report: Provided
- Video outgoing-inspection: Provided
- Core Components: Other, laser source, laser head
- Mode of Operation: continuous wave
- Configuration: 4-axis
- Products handled: Sheet Metal
- Feature: Fully-enclosed
- Maximum Speed: 80m/min
- Warranty of core components: 2 years
- Type: fiber laser cutting
- Cutting materials: Gold Silver Sheet
- After-sales Service Provided: Video Technical Support
1. The high-precision linear motor unit has a compact structure and no mechanical contact, which greatly reduces the power loss. Less friction provides greater performance for cutting accuracy and speed.
2.Automatically monitor the operating range of the beam and cutting parts, and the sensitive feedback makes it stop quickly. And there is a fixed limit double guarantee, which greatly improves the equipment and personal protection, and reduces the customer's use risk.
3.
Stable running: adopt top world import fiber lasers, stable performance, key parts can
reach 100,000 hours;
4. High efficiency for photoelectric conversion: Compare with CO2 laser cutting machine, fiber laser cutting machine have three times photoelectric conversion efficiency.
5.Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.
6.Low maintenance: fiber line transmission no need reflect lens, save maintenance cost;
Machine scope
Widely used in the processing of metal tube structure, advertising board, spring coil slice,
textile machinery parts, kitchen utensils, car, machinery, elevator, electric parts, subway line spare parts, etc. Suitable for stainless steel, carbon steel, silicon steel, aluminum alloy, titanium alloy, galvanized steel, aluminum- plating zinc plate, copper and other metals.
*After placing an order, the delivery lead time is usually within 10 working days
height:1819MM width:1515MM Length:1798MM
*The size is manually measured and there will be a little error
|
Laser Type
|
Fiber Laser
|
|
Laser Power
|
1500W 2000w 3000w
|
|
Laser Source
|
MAX IPG RAYCUS
|
|
Working Area
|
6000mmX6000mm
|
|
Laser Wave Length
|
1064nm
|
|
Position Accuracy
|
±0.05mm/m
|
|
Maximum Running Speed
|
90m/min
|
|
Working Voltage
|
380V 3 PHASE 50hz/60hz
|
|
Warranty
|
2 Years
|
|
Laser Power
|
Gold
|
Silver
|
Brass
|
Stainless Steel
|
|
1500W
|
2mm
|
1.5mm
|
2mm
|
4mm
|
|
2000W
|
3mm
|
2mm
|
3mm
|
5mm
|
|
3000W
|
4mm
|
3mm
|
4mm
|
8mm
|
Warranty and after-sales service
1.This machine has a 2 years warranty. You can see the warranty card, service card,
operation video, and user manual on this machine.
2.During the warranty period, if any part is damaged, we will provide you with new parts for free, and the freight will be borne by us (you will never be required to return old parts, and some manufacturers will require customers to return damaged parts)
3.Even if your machine is out of warranty period, if you encounter any problems, you can
call our service center or contact your sales staff. We will help you solve the problem
within 12 hours. We have a team of after-sales engineers in English, Japanese, and
Russian, and we can provide support services that small factories cannot provide.
WHY CHOOSE US
Optical Technology (Shenzhen) Co., Ltd. is a comprehensive enterprise integrating R&D, design and
production.
Product laser automation equipment manufacturer. Our products include laser cutting machines, marking
machines, laser welding machines, laser engraving machines and non-standard automation equipment.
Our company has a group of high-level optical, electronic and precision mechanical researchers, and has world-class optical and microelectronic test equipment, advanced quality, management system, improve the efficiency of the manufacturing test process, and create excellent quality.
Our commitment is to focus on product quality and customer service through research and continuous improvement of technical level, development, standardization, and scientific management.
Optical Technology (Shenzhen) Co., Ltd. has won a good reputation in Germany,
the United States, Japan, the United Kingdom, Russia, Malaysia and other countries.
Optical Technology (Shenzhen) Co., Ltd. has established a long-term friendly cooperative relationship
with domestic laser research institutes. Over the years, our products have been exported to more than
one hundred countries and regions.
FAQ
1.What is the machine warranty and after sale service?
We will provide instruction videos and operation manuals to help you operate the machine. During covid19, we can provide whatsapp videos and WeChat online videos teach you how to use the machine step by step. The machine has 2 years of after-sales service. During the warranty period, if there is any quality problem with the machine, we will replace with new parts and send it to you by express. Our freight. If there is any problem with the quality of the machine more than 2 years warranty, our after sales service team will help you solve it within 8 hours.
2. Is this machine has quickly-wear part?
2. Is this machine has quickly-wear part?
The life of the precision laser cutting machine is more than 100,000 hours. A better working environment can extend the life. Nitrogen will be consumed as a protective gas. 3. Will the package be damaged during transportation?
Our packages take all damage factors into consideration and make sure the product will be in safe transportation. We have exported to 180 countries worldwide. So transportation won't be problem for us and customers will definitely receive products in good condition.
