Talha elétrica capacidade 10 toneladas com trolé Motorizado Tensão Elétrica 220/380/400/415/460/525 volts

, Author

Promoção!

O preço original era: R$ 38.677,20.O preço atual é: R$ 35.498,70.

Up to 12 installments without cards through Mercado Credito. Learn more
Buy through Mercado Credito without cards and pay month by month
1
Add your product to the cart and, for the payment, select Mercado Credito.
2
Log in to Mercado Pago.
3
Choose the amount of installments that best suit you and you’re all set!

Credit subject to approval.

Any Questions? Check our Help.

REF: 1005003908597629 Categoria:

Descrição

  • Origem: CN (Origem)
  • Certificado: CE
  • Condition: New
  • Place of Origin: China
  • Brand Name: TXK
  • Usage: Construction Hoist
  • Power Source: Electric
  • Sling Type: Chain
  • Lift Speed: 2.7 & 0.9 m/min
  • Certification: CE, ISO, SGS
  • Warranty: 1 Year
  • After-sales Service Provided: Free spare parts
  • Power Supply: 220-690V, 3 Phase or Single Phase
  • Control Voltage: 24V/36V/48V or 110V
  • Lifting Height: 3m-130m
  • Working Group: ISO:M4, Fem:1am
  • Protection Grade: IP54 for Hoist Body, IP55 for Pendant
  • Bearing: Japan NSK Brand
  • Noise: 81dB
  • Hooks: Heat Forging Heat Treatment
  • Contactor: :Eaton / Schneider

Modelo SSDHL
7.5-03S 7.5-03D 10-04S 10-04D 15-06S 15-06D 20-08S 20-08D 25-10S 25-10D
Capacidade (t) 7.5t 10t 15t 20t 25t
Velocidade de elevação (m/min) 1.8 1.8/0.6 2.7 2.7/0.9 1.8 1.8/0.6 1.4 1.5/0.5 1.1 1.2/0.4
Potência do motor (kw) 3.0 3.0/1.0 3.0*2 3.0*2/1.0*2 3.0*2 3.0*2/1.0*2 3.0*2 3.0*2/1.0*2 3.0*2 3.0/1.0
Velocidade de rotação (r/min) 1440 2880/960 1440 2880/960 1440 2880/960 1440 2880/960 1440 2880/960
Grau de isolamento F
Fonte de Alimentação 3p 220v ~ 690v
Tensão de controle 24v/36v/48v
Não. de Cadeia 3 3 4 4 6 6 8 8 10 10
Especificação da corrente de carga Ø11.2
Peso líquido (kg) 176 215 300 380 382 455 482 545 503 579
Embalagem & Grátis

Detalhes da embalagem:Caixas de madeira compensada (embalagem livre de fumigação)

Detalhes do envio: 7 dias de entrega rápida

Descrição do produto

TXK Talha Elétrica de Corrente

1. escudo da liga de alumínio, leve mas duro.

2. corrente de carga g80 ou corrente de carga japão pec g80, pode ser usado no ambiente áspero.

3. gancho: quente forjado com força perfeita, difícil de quebrar.

4. botão de pressão, controle remoto: importado de taiwan.

5. talha chain elétrica trifásica & monofásica, ambos são opcionais

220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley 220/380/400/415/460/525 Volts 10 ton Goods Lifting Electrical Winch with Motorized Trolley
